Product Introduction


Rugged Tablet PC

ST827 adopts Qualcomm MSM8953 Octa core 2GHz CPU and Android 7.1 operation system;4G RAM,64G ROM,4G LTE.

1980*1200 or 1280*800 LCD screen is readable under sunlight; Optional functions like barcode scanning, RFID reader, fingerprint identification

It has 10000mAH battery; IP67 high reliable three-proof structure water/dust proof; drop resistance from 1.2m.


FEATURES


Advanced system

Android 7.1 operating system; CPU MSM8953, 8 core, 2GHz CPU; RAM 4GB ROM 64GB, Micro SD 128G

Visible under strong light

8 inch LCD screen, touch screen or 1280*800

Powerful function

Multi function1D/2D bar code scanning, LF/HF/UHF RFID reader, fingerprint identification)

Multi communication modes

3G/4G, WIFI, Bluetooth and many wireless communication modes

Support jacket extension

Satisfy custom applications from customers

Certification

CCC/CE/ROSH/FCC/IP67/MIL-STD-810

SPECIFICATIONS

Standard function

Operating System

Android 7.1

CPU

MSM8953, 8 core CPU, 2GHz

RAM

RAM: 4GB

FLASH: 64GB

Extended Storage

Micro SD, Maximum 128G

USB port

5 pin MicroUSB; Support to connect U-disk/Mouse/Keyboard/OTG line

HDMI

HDMI port

OTG

Through OTG can meet 100M network port, network card setup, PPPoE dial-up, web browsing. Support OTG extend RS232 serial port/485 serial port/RJ45 Serial port

External port

Charge port, headphone port

Protection Grade

Industrial Protection Grade

IP67

Drop Grade

Drop resistance from 1.2m

Wireless Communication

Bluetooth

Support 4.0

GPS

GPS+BDS +GLONASS

Qualcomm GPS 3m

WIFI

Support IEEE 802.11a/b/g/n/ac

2G/3G/4G LTE

GSM 850/900/1800/1900   B5/B8/B3/B2

WCDMA B1/B2/B4  2100/1900/1700

TD-SCDMA B34/B39

FDD-LTE: B1/B3/B5/B7/B8  2100/1800/850/2600/900

TDD-LTE :

Band38:2570 MHz - 2620 MHz

Band39: 1880 MHz - 1920 MHz

B41:2555-2655MHz

B40/:2300-2400MHz B38/B39/B41/B40/  B38/B39/B40/B41

Physical Parameters

Display Screen

8 inch LCD screen, 800*1280 450 nits

Keyboard

Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset

Camera

5 million pixels front camera, 13 million pixels rear camera with automatic focus and lighting function

Headset

   3.5mm audio Interface, has MIC and Single loudspeaker

·         LED indicator light

   Support (ordinary flicker, Call fast flicker, missed calls, charge indicator)

·         Flashlight Function

S  Support, can be used for emergency lighting

         Googleplay store

S  Support

·           Gravity sensor

Support

·            Compass

Support

Gyroscopes

NOT Support

Acceleration sensors

Support

Light and distance sensor

Support

Vibrating motor

Support

FM

Support

Rechargeable Lithium Battery

3.8V, 10000mAh

Dimension

232*158*22

Weight

810g

Environmental Characteristics

Working Temperature

-10 ~ +50

Storage Temperature

-40 ~ +60

Humidity

5%-95% relative humidity; no condensation

Optional function

Barcode Scanning

1D Laser Scanner Index(Internal):

Honeywell N4313 or Zebra EM1350

Scanning speed: 104 times/second+12 times/second (two way scanning)

Scanning distance: 2.5cm-114.3cm

Scanning angle: 47±3°(default) /35±3°(reduced code)

2D Barcode Scanner Index(Internal):

Newlands EM3096

Honeywell N3680

Motorola SE4750

Identification ability: 1D, 2D, OCR

Scanning angle: rotate 360°, incline±50°, deflection ±50°

Field of View: Horizontal 36°, vertical 23°

Depth of field: 4cm-23.5cm

Environmental luminance: 0~100,000 LUX

RFID

HF RFID(Internal):

Support NFC/NXP,13.56MHZ ISO14443A,B and ISO15693 protocol, reading distance 0-3cm,Tag support type:SR176,SRIX4KTYPE-B,I-Code2,TI RFID Tag-it HF-I,EM4034,Mifare Classic ETC

LF RFID:

134.2KHZ LF RFID, support ISO11784/5 protocol, support to read IC card(FDX/HDX)

125KHZ LF RFID, support to read ID card

UHF RFID



Internal

Ray links RLM060 or ThingMagic M6E-NANO,EPC C1 GEN2/ISO 18000-6C,output power 10dBm-30dBm

Reading distance: 1 m

Ceramic antenna: 0.3db(25*25*4mm)



Far infrared meter reading

Working frequency 37.9K


                            Functions

Order code

Description

standard

Qualcomm MSM8953 Octa core, 2GHZ CPU,android 7.1,4G RAM,,64G ROM,13MP camera,8 inch LCD,Bluetooth,wifi

ST907V3.0

GSM 850/900/1800/1900   B5/B8/B3/B2

WCDMA B1/B2/B4  2100/1900/1700

TD-SCDMA B34/B39

FDD-LTE: B1/B3/B5/B7/B8 2100/1800/850/2600/900

TDD-LTE :

Band38:2570 MHz - 2620 MHz

Band39: 1880 MHz - 1920 MHz

B41:2555-2655MHz

B40/:2300-2400MHz B38/B39/B41/B40/  B38/B39/B40/B41

Optional





NFC RFID

H

13.56Mhz RFID

GPS

G

GPS+BDS+GLONASS

B

GPS+BDS, Qualcomm solution

1D barcode

N

1D barcode scanner N4313 Honeywell

Z

1D barcode scanner EM1350 Zebra

2Dbarcode



2

2D newland 3096 barcode scanner

8

2D Honeywell 3680

7

2D SE4750 symbol barcode scanner

LF RFID

4

LF134KHz(FDX) RFID 3cm

5

LF 125KHz RFID



L

LF134KHz(FDX) RFID 10cm

UHF RFID

Q

UHF RFID M6W-NANO

infrared meter reading

T

infrared meter reader(not available)








};
